HX-1GE GPON ONU

Product Show/ PRODUCT

Copyrights Reserved

Product description/ PRODUCT

HX-1GE ONU is a simple but functional design specially for use with FTTH/FTTO to provide the data and video service based on the GPON network. It provides 10/100/1000 Mbps based Ethernet networks. With one optical interface, supported router function in highly impacted.Specially suitable for home and small business users and the FTTH high-speed data transmission of the application.

Product Show/ PRODUCT

Product Features / PRODUCT

■ Supports the configuration of Ethernet interface rates, working modes, MDI/ MDIX auto-negotiation mode, and Pause flow control;
■ Supports packet filtering and protection against illegal message attacks: suppresses unknown unicast, multicast and broadcast packets;
■ Provides performance statistics on all Ethernet lines;
■ Supports IGMP snooping protocol;
■ Supports the L2 wire speed forwarding;
■ Supports the WEB configuration function;
■ Supports the AES-128 algorithm for data encryption of downlink data;
■ Performs various QoS functions: supporting global configuration of queue priority and flexible mapping of 802. 1p value of packets;
■Supports the PQ queue scheduling mode;

Product standard/ PRODUCT

EPON IEEE802.3ah

Technical Parameters / PRODUCT

Fiber port:	1 GPON interface, SC single-mode/single-fiber, Downstream rate 2.5Gbps, Upstream rate 1.25Gbps
Wavelength	Tx 1310nm, Rx 1490nm
RX sensitivity	<-28dBm (1490nm)
WLAN	IEEE802.11b/g/n,300Mbps, a built-in antenna
LAN	1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface
Throughput	Throughput can reach 900Mbps or more
DC power	12V 1A, external AC-DC power adapter
Button	Reset
Power	≤8W
Operation	Working temperature: -5-+55℃ working humidity:10-90%(non-condensation)
Storage	Storage temperature: -30℃-+60℃ storage humidity: 10-90%(non-condensation)
Volume and weight	858927.5mm/0.2kgs
