FTTH sreel wire drop cable GJYXCH

Product Show/ PRODUCT

Copyrights Reserved

Product description/ PRODUCT

The optical fiber unit is positioned in the centre. Two parallel Fiber Reinforced Plastics (FRP) are placed at the two sides. A steel wire as the additional strength member is also applied. Then the cable is completed with a black or color LSZH sheath,There is a recognition guide at the bottom of the cable.

Product Description/ PRODUCT


Product Export Containers/ PRODUCT

Daily export 6 containers

Characteristics/ PRODUCT

· Special low-bend-sensitivity fiber provides  high bandwidth and excellent communication
transmission property;
· Two parallel FRP strength members ensure good performance of crush resistance  to protect the
fiber;
· Single steel wire or messengers as the additional strength member ensures  good performance of  tensile strength;
· Simple structure, light weight and high practicability;
· Novel flute design, easily strip and splice, simplify the installation and  maintenance;
· Low smoke, zero halogen and flame retardant sheath.

Optical Characteristics/ PRODUCT


G.652

G.657

50/125μm

62.5/125μm

Attenuation
     (+20℃)

@850nm



≤3.5    dB/km

≤3.5    dB/km

@1300nm



≤1.5    dB/km

≤1.5    dB/km

@1310nm

≤0.40    dB/km

≤0.40    dB/km



@1550nm

≤0.30    dB/km

≤0.30dB/km



Bandwidth (Class A)

@850nm



≥500    MHz·km

≥200 MHz·km

@1300nm



≥500    MHz·km

≥500    MHz·km

Numerical Aperture



0.200±0.015NA

0.275±0.015NA

Cable Cut-off    Wavelength

≤1260nm

≤1260nm




Technical Parameters/ PRODUCT

Fiber count

Cable Diameter mm

Cable Weight kg/km

Tensile Strength Long
     /Short Term N

Crush
     Resistance    Long
     /Short    Term N/100mm

Bending Radius Static /Dynamic mm

1

(2.0±0.2)×(5.0±0.2)

20

300/600

1000/2200

20/40

2

(2.0±0.2)×(5.0±0.2)

20

300/600

1000/2200

20/40

4

(2.0±0.2)×(5.0±0.2)

20

300/600

1000/2200

20/40

6

(2.5±0.2)×(6.0±0.2)

26

300/600

1000/2200

20/40

8

(2.5±0.2)×(6.0±0.2)

26

300/600

1000/2200

20/40

12

(3.0±0.2)×(7.0±0.2)

34

300/600

1000/2200

20/40

Storage/Operating  Temperature : -20℃ to + 60℃
