HX-1GE+1FE+WiFi EPON ONU

Product Show/ PRODUCT

Copyrights Reserved

Product description/ PRODUCT

HX-1GE+1FE+WiFi dual mode ONU meets telecom operators FTTO (office), FTTD(Desk), FTTH(Home) broadband speed, SOHO broadband access, video surveillance and other requirements and design an GPON/GEPON Gigabit Ethernet products. It is based on mature GPON and Gigabit EPON technology, and has high ratio of performance to price, stable, cost-effective, high reliability, easy management, configuration flexibility and good quality of service (QoS) guarantees. It is fully compliant with GPON and EPON technical regulations such as ITU-T G.984.x, IEEE802.3ah and technical requirement of EPON Equipment

Product Show/ PRODUCT

Product Features / PRODUCT

Plug and play, features auto-detecting, auto-configuration, and auto firmware upgrade, etc.
Integrated OAM remote configuration and maintenance function.
Support rich QinQ VLAN functions and IGMP Snooping multicast features.
Fully compatibility with OLT based on popular chipset.
Support 802.11n WiFi(2T2R) function.
Support NAT, Firewall function.
Support IPv4 and IPv6 dual stack.
The WAN port supports bridge, router and bridge/router mixed mode.

Product standard/ PRODUCT

EPON IEEE802.3ah

Technical Parameters / PRODUCT

Technical item	1GE+1FE+WiFi
Interface	1 GPON/EPON interface, SC single-mode/single-fiber.
Interface	GPON: uplink 1.25Gbps, downlink 2.5Gbps; EPON: symmetric 1.25Gbps.
Wavelength	PON Tx1310nm,Rx 1490nm
LAN interface	1x 10/100/1000Mbps Auto-negotiation Ethernet interfaces.
	1x10/100Mbps Auto-negotiation Ethernet interfaces.
	RJ45 connector
Wireless	Compliant with IEEE802.11b/g/n, 300Mbps, 2T2R, 2 external antenna
LED	6, For Status of POWER、LOS、PON、LAN、WiFi.
Operating condition	Temperature: -5℃～55℃
Operating condition	Humidity: 10%～90%（non-condensing）
Storing	Temperature :-30℃～60℃
condition	Humidity :10%～90%（non-condensing）
Power supply	DC 12V/1A
Power consumption	≤7W
Dimension	185mm×120mm×34mm（L×W×H）
Net weight	0.24Kg
